| B/F系列产品 | ||||
| 1 潍柴全新一代轻型柴油发电机组 Weichai new generation light diesel gen-sets 3 低排放、低噪音，优良的环保性能 Low emissions,low noise,good environmental protection performance 5 适合多种应用场景的结构/功能解决方案 Professional structure/function solution for varieties of scenarios | 2 高可靠性，高功率密度 High reliability,high power density 4 专业的发电机组应用集成能力 Professional application & integration capabilities for gen-sts 6 具备国内各类产品认证资质以及CE认证 Have kinds of domestic product certification and CE certification | |||
| 机组型号Gensets Model | WPG55B1 | WPG68B1 | WPG88B1 | WPG110B1 |
| 额定功率/容量(kW/kVA) Rated Power/Capacity | 40/50 | 50/62.5 | 64/80 | 80/100 |
| 备用功率/容量(kW/kVA) Standby Power/Capacity | 44/55 | 55/68.5 | 70.4/88 | 88/110 |
| 发动机型号Engine Model | WP4.1D66E200 | WP4.1D66E200 | WP4.1D80E200 | WP4.1D100E210 |
| 额定功率(kW)Rated Power | 60 | 60 | 72 | 90 |
| 备用功率（kW）Standby Power | 66 | 66 | 80 | 100 |
| 气缸数-缸径×行程(mm) Cylinder No.-Bore×Stroke | 4-105×118 | |||
| 排量（L）Displacement | 4.1 | |||
| 启动方式Starting Method | DC24V电启动 Electrical Starting | |||
| 调速方式Speed Governor | 机械调速/电子调速 Mechanical/Electronic | |||
| 进气方式Intake Way | 涡轮增压 Turbocharged | 增压中冷 Turbo＆Inter-cooling | ||
| 机油容量(L)Oil Capacity | 13 | |||
| 冷却液容量（L） Coolant Capacity | 18 | |||
| 经济燃油消耗率(g/kW.h) Economic Fuel Consumption | 210 | |||
| 额定电压（V） Rated Voltage | 400/230 | |||
| 频率(Hz)Frequency | 50 | |||
| 额定电流(A)Rated Current | 72 | 90 | 115 | 144 |
| 额定功率因数Rated Factor | 0.8（滞后lag） | |||
| 相数及接法 Phase No.& Connection | 三相四线，星型接法 3P4W,Y Style Connection | |||
| 调压方式 Voltage Regulation Mode | 自动调压AVR | |||
