| B/F系列产品 | ||||||
| 1 源自欧洲技术，自主研发 Original European technology，independent R&D 3 全球第一销量发动机动力 The world's first sales engine power 5 适合多种应用场景的结构/功能解决方案 Professional structure/function solution for varieties of scenarios | 2 行业先进的产品性能指标 Excellent product performance indicators leading industry 4 专业的发电机组应用集成能力 Professional application & integration capabilities for gen-sts 6 具备国内各类产品认证资质以及CE认证 Have kinds of domestic product certification and CE certification | |||||
| 机组型号Gensets Model | WPG206B8 | WPG247.5B8 | WPG250B8 | WPG275B8 | WPG344B8 | WPG375B8 |
| 额定功率/容量(kW/kVA) Rated Power/Capacity | 150/187.5 | 180/225 | / | 220/250 | 250/312.5 | / |
| 备用功率/容量(kW/kVA) Standby Power/Capacity | 165/206 | 198/247.5 | 200/250 | 220/275 | 275/344 | 300/375 |
| 发动机型号Engine Model | WP10D200E200 | WP10D238E200 | WP10D238E200 | WP10D264E200 | WP10D320E200 | WP10D320E200 |
| 额定功率(kW)Rated Power | 182 | 216 | 216 | 240 | / | / |
| 备用功率（kW）Standby Power | 200 | 238 | 238 | 264 | 320 | 320 |
| 气缸数-缸径×行程(mm) Cylinder No.-Bore×Stroke | 6-126X130 | |||||
| 排量（L）Displacement | 9.726 | |||||
| 启动方式Starting Method | DC24V电启动 Electrical Starting | |||||
| 调速方式Speed Governor | 电子调速 Electronic | |||||
| 进气方式Intake Way | 增压中冷 Turbo & Inter-cooling | |||||
| 机油容量(L)Oil Capacity | 23 | |||||
| 冷却液容量（L）Coolant Capacity | 51 | |||||
| 经济燃油消耗率(g/kW.h)Economic Fuel Consumption | 198 | |||||
| 额定电压（V）Rated Voltage | 400/230 | |||||
| 频率(Hz)Frequency | 50 | |||||
| 额定电流(A)Rated Current | 271 | 324 | 361 | 361 | 451 | 541 |
| 额定功率因数Rated Factor | 0.8（滞后lag） | |||||
| 相数及接法 Phase No.& Connection | 三相四线，星型接法 3P4W,Y Style Connection | |||||
| 调压方式 Voltage Regulation Mode | 自动调压AVR | |||||
