| B系列产品 | |||
| 1 法国品牌，军工品质,行业先进的大功率柴油发电机组 France brand,military quality。The most excellent superpower dieselgen-sets leading industry 3 卓越的启动性能，为您的电源设备保驾护航 Superior starting performance,escorting your power equipment 5 采用电控高压共轨技术，排放达到国III要求，具备扩展 国IV的能力 Adopting electric control high pressure common rail technology,achieving non-road emission stage III standard,possessing the ability of extending non-road emission stage iv standard 7获得通信行业泰尔认证证书及第三方机组检测报告 Obtain the TL certification of the communication industry and third party test report | 2 自主ECU核心技术，全面保证信息安全 Core-technology of self-developed ECU which guarantees information safety 4 高可靠性，超长大修期达32000h High reliability,super-long overhaul periof for 32000h 6 专业的发电机组应用集成能力 Professional application & integration capabilities for gen-sets | ||
| 机组型号Gensets Model | WPG2200B7 | WPG2475B7 | WPG2500B7 |
| 额定功率/容量(kW/kVA) Rated Power/Capacity | 1600/20000 | 1800/2250 | / |
| 备用功率/容量(kW/kVA) Standby Power/Capacity | 1760/2200 | 1980/2475 | 2000/2500 |
| 发动机型号Engine Model | 12M55D2000E310 | 12M55D2200E310 | 12M55D2200E310 |
| 额定功率(kW)Rated Power | 1390 | 1430 | 1500 |
| 备用功率（kW）Standby Power | 1527 | 1573 | 1650 |
| 气缸数-缸径×行程(mm) Cylinder No.-Bore×Stroke | 12-180X215 | ||
| 排量（L）Displacement | 65.65 | ||
| 启动方式Starting Method | DC24V电启动 Electrical Starting | ||
| 调速方式Speed Governor | 电控ECU | ||
| 进气方式Intake Way | 增压中冷 Turbo & Inter-cooling | ||
| 机油容量(L)Oil Capacity | 480 | ||
| 冷却液容量（L） Coolant Capacity | 650 | ||
| 经济燃油消耗率(g/kW.h) Economic Fuel Consumption | 185 | ||
| 额定电压（V）Rated Voltage | 400/230 | ||
| 频率(Hz)Frequency | 50 | ||
| 额定电流(A)Rated Current | 2887 | 3248 | 3609 |
| 额定功率因数Rated Factor | 0.8（滞后lag） | ||
| 相数及接法 Phase No.& Connection | 三相四线，星型接法 3P4W,Y Style Connection | ||
| 调压方式 Voltage Regulation Mode | 自动调压AVR | ||
